Engine Two Stroke 3 Cylinder
Output 50 ps (36.8 kw)
Displacement 697 cc (42.53 cu.in.)
Bore x Stroke 68 x 64 mm (2.68 x 2.52 in)
Starting Electric or Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.08 (13:27)
Propeller Selection Range 7" - 17"
Transom Height 15", 20", 22.5", 25"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 25 L (6.6 US Gal.) Separate Fuel Tank
Weight* 72 Kg (159 lbs.)
Alternator Output Optional: 12V, 130W, 11A (Standard on Electric Start Model)
Max. RPM Range 5,000 - 5,800
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Overheat Buzzer 0
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Type 90 deg. V6
Displacement [cm3] 2596
Bore x Stroke [mm] 90.0 x 68.0
Max. Prop Shaft Output [kW (ps)] @r/min 147.1 (200) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] L: 516 (20.3), X: 642 (25.3) (*depending on model)
Dry Weight [kg] * 178-186
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Pre-mixed Fuel and Oil
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Engine Type In-line 3
Displacement [cm3] 1140
Bore x Stroke [mm] 82.0 × 72.0
Max. Prop Shaft Output [kW (ps)] @r/min 55.2 (75) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] L: 516 (20.3) or 521 (20.5), Y: 572 (22.5), X: 643 (25.5) or 648 (25.5) (*depending on model)
Dry Weight [kg] * 112-121
Starting System Manual Starter or Manual & Electric Starter (*depending on model)
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Hydro Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 3
Displacement [cm3] 849
Bore x Stroke [mm] 72.0 × 69.5
Max. Prop Shaft Output [kW (ps)] @r/min 44.1 (60) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 450 (17.7), L: 571 (22.5), X: 648 (25.5) (*depending on model)
Dry Weight [kg] * 96-105
Starting System Manual Starter or Manual & Electric Starter (*depending on model)
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Manual Tilt or Power Trim & Tilt (*depending on model)
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 2
Displacement [cm3] 703
Bore x Stroke [mm] 80.0 x 70.0
Max. Prop Shaft Output [kW (ps)] @r/min 29.4 (40) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 424 (16.7), L: 550 (21.7), X: 649 (25.6) (*depending on model)
Dry Weight [kg] * 72-81
Starting System Manual Starter or Manual & Electric Starter (*depending on model)
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Manual Tilt or Power Trim & Tilt (*depending on model)
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 2
Displacement [cm3] 669
Bore x Stroke [mm] 78.0 x 70.0
Max. Prop Shaft Output [kW (ps)] @r/min 29.4 (40) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 421 (16.6), L:548 (21.6), Y: 598 (23.5) (*depending on model)
Dry Weight [kg] * 65-71
Starting System Manual Starter or Manual & Electric Starter (*depending on model)
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 2
Displacement [cm3] 496
Bore x Stroke [mm] 72.0 x 61.0
Max. Prop Shaft Output [kW (ps)] @r/min 22.1 (30) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 423 (16.7), L: 550 (21.7) (*depending on model)
Dry Weight [kg] * 53-58
Starting System Manual Starter or Manual & Electric Starter (*depending on model)
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 2
Displacement [cm3] 246
Bore x Stroke [mm] 56.0 x 50.0
Max. Prop Shaft Output [kW (ps)] @r/min 11.0 (15) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 441 (17.4), L: 568 (22.4), X: 710 (30.3)
Dry Weight [kg] * 38-41
Starting System Manual Starter
Controls Tiller Handle
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 2
Displacement [cm3] 165
Bore x Stroke [mm] 50.0 × 42.0
Max. Prop Shaft Output [kW (ps)] @r/min 5.9 (8) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 442 (17.4), L: 582 (22.9)
Dry Weight [kg] * 28-29
Starting System Manual Starter
Controls Tiller Handle
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type In-line 3
Displacement [cm3] 1140
Bore x Stroke [mm] 82.0 x 72.0
Max. Prop Shaft Output [kW (ps)] @r/min 62.5 (85) @5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] L: 521 (20.5), Y: 572 (22.5), X: 647 (25.5) (*depending on model)
Dry Weight [kg] * 113-124
Starting System Electric Starter
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Power Trim & Tilt or Hydro Tilt (*depending on model)
Lubrication System Pre-mixed Fuel and Oil
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Engine Type 1-Cylinder
Displacement [cm3] 103
Bore x Stroke [mm] 54.0 x 45.0
Max. Prop Shaft Output [kW (ps)] @r/min 2.9 (4) @ 5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 444 (17.5)
Dry Weight [kg] * 21
Starting System Manual Starter
Controls Tiller Handle
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type 1-Cylinder
Displacement [cm3] 70
Bore x Stroke [mm] 46.0 x 42.0
Max. Prop Shaft Output [kW (ps)] @r/min 2.2 (3) @ 5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 440 (17.3)
Dry Weight [kg] * 17
Starting System Manual Starter
Controls Tiller Handle
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type 1-Cylinder
Displacement [cm3] 50
Bore x Stroke [mm] 42.0 x 36.0
Max. Prop Shaft Output [kW (ps)] @r/min 1.5 (2) @ 5000
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 419 (16.4)
Dry Weight [kg] * 10
Starting System Manual Starter
Controls Tiller Handle
Tilt System Manual Tilt
Lubrication System Pre-mixed Fuel and Oil
Engine Type 24-valve, DOHC with VCT, 60 deg. V6
Displacement [cm3] 4169
Bore x Stroke [mm] 96.0 x 96.0
Max. Prop Shaft Output [kW (ps)] @r/min 220.6 (300) @5500
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] X: 642 (25.3), U: 769 (30.3)
Dry Weight [kg] * 269-276
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type 24-valve, DOHC with VCT, 60 deg. V6
Displacement [cm3] 4169
Bore x Stroke [mm] 96.0 x 96.0
Max. Prop Shaft Output [kW (ps)] @r/min 220.6 (300) @5500
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] X: 643 (25.3), U: 770 (30.3)
Dry Weight [kg] * 260-268
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type 24-valve, DOHC with VCT, 60 deg. V6
Displacement [cm3] 3352
Bore x Stroke [mm] 94.0 × 80.5
Max. Prop Shaft Output [kW (ps)] @r/min 183.9 (250) @ 5500
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] X: 643 (25.3), U: 770 (30.3)
Dry Weight [kg] * 283-289
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type 24-valve, DOHC with VCT, 60 deg. V6
Displacement [cm3] 4169
Bore x Stroke [mm] 96.0 x 96.0
Max. Prop Shaft Output [kW (ps)] @r/min 183.8 (250) @5500
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] X: 643 (25.3), U: 770 (30.3)
Dry Weight [kg] * 260-268
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type 24-valve, DOHC with VCT, 60 deg. V6
Displacement [cm3] 3352
Bore x Stroke [mm] 94.0 x 80.5
Max. Prop Shaft Output [kW (ps)] @r/min 147.1 (200) @5500
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] X: 643 (25.3), U: 770 (30.3)
Dry Weight [kg] * 283-289
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type 16-Valve, DOHC, In-line 4
Displacement [cm3] 2670
Bore x Stroke [mm] 94.0 x 96.2
Max. Prop Shaft Output [kW (ps)] @r/min 110.3 (150) @5000
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] X: 643 (25.3)
Dry Weight [kg] * 223
Starting System Electric Starter
Controls Remote Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type 16-Valve, DOHC, In-line 4
Displacement [cm3] 1832
Bore x Stroke [mm] 81.0 x 88.9
Max. Prop Shaft Output [kW (ps)] @r/min 84.6 (115) @5800
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] L: 516 (20.3), X: 643 (25.3) (*depending on model)
Dry Weight [kg] * 175-185
Starting System Electric Starter
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Engine Type SOHC, In-line 2
Displacement [cm3] 747
Bore x Stroke [mm] 65.0 x 75.0
Max. Prop Shaft Output [kW (ps)] @r/min 29.4 (40) @5500
Fuel Induction System Fuel Injection
Engine Transom Height [mm (inch)] S: 414 (16.3), L: 536 (21.1) (*depending on model)
Dry Weight [kg] * 91-106
Starting System Electric Starter
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Power Trim & Tilt or Hydro Tilt (*depending on model)
Lubrication System Wet Sump
Digital Network Available
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Engine Two Stroke 2 Cylinder
Output 30 ps 22.1 kw)
Displacement 429cc (26.16 cu.in.)
Bore x Stroke 68 x 59 mm (2.68 x 2.32 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 1.92:1 (12:23)
Propeller Selection Range 8" - 14"
Transom Height 15", 20", 25"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 25 L (6.6 US Gal.) Separate Fuel Tank
Weight* 51.0 Kg (112 lbs.)
Alternator Output Optional: 12V, 80W, 7A
Max. RPM Range 5,150 - 5,850
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine
Type 4-Stroke DOHC 4 Cylinder/16 Valves
Displacement 2,354cc (144 cubic ins.)
Bore & Stroke 87 mm x 99 mm (3.4 x 3.9 inches)
Full Throttle RPM Range 5,000-6,000 RPM
Rated Power 150 HP @ 5,500 RPM
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 72°
Drive
Gear Ratio 2.14:1
Gear Shift F-N-R
Alternator (Electric Start) 51 Amp
Battery Charging Power 30 Amp (1,000 RPM), 40 Amp (2,000+ RPM)
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 580 mm/22.8 inches
Transom Height
X Type 635 mm/25 inches
Dry Weight
X-Type 220 kg/485 lbs.
Engine Two Stroke 2 Cylinder
Output 25 ps (18.4 kw)
Displacement 429cc (26.16 cu.in.)
Bore x Stroke 68 x 59 mm (2.68 x 2.32 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 1.92:1 (12:23)
Propeller Selection Range 8" - 14"
Transom Height 15", 20", 25"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 25 L (6.6 US Gal.) Separate Fuel Tank
Weight* 51.0 Kg (112 lbs.)
Alternator Output Optional: 12V, 80W, 7A
Max. RPM Range 5,000 - 6,000
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 2 Cylinder
Output 18 hp (13.2 kw)
Displacement 294 cc (17.94 cu.in.)
Bore x Stroke 60 x 52 mm (2.36 x 2.05 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 1.85:1 (13:24)
Propeller Selection Range 6" - 11.5"
Transom Height 15", 20", 25"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 25 L (6.6 US Gal.) Separate Fuel Tank
Weight* 41 Kg (90 lbs.)
Alternator Output Optional: 12V, 80W, 7A
Max. RPM Range 5,200 - 5,800
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 2 Cylinder
Output 9.8 ps (7.2 kw)
Displacement 169 cc (10.31 cu.in.)
Bore x Stroke 50 x 43 mm (1.97 x 1.69 in)
Starting Electric or Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.08:1 (13:27)
Ignition System ATDC1゜- BTDC17゜
Propeller Selection Range 5" - 9.5"
Transom Height 15", 20", 25"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 12 L (3.17 US Gal.) Separate Fuel Tank
Weight* 26.0 Kg (57 lbs.)
Alternator Output Optional: 12V, 80W, 7A (Standard on Electric Start Models)
Max. RPM Range 5,000 - 6,000
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 2 Cylinder
Output 8 hp (5.9 kw)
Displacement 169 cc (10.31 cu.in.)
Bore x Stroke 50 x 43 mm (1.97 x 1.69 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.08:1 (13:27)
Propeller Selection Range 5" - 9.5"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 12 L (3.17 US Gal.) Separate Fuel Tank
Weight* 26.0 Kg (57 lbs.)
Alternator Output Optional: 12V, 80W, 7A
Max. RPM Range 4,500 - 5,500
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 2 Cylinder
Output 6 ps (4.4 kw)
Displacement 169 cc (10.31 cu.in.)
Bore x Stroke 50 x 43 mm (1.97 x 1.69 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.08:1 (13:27)
Propeller Selection Range 5" - 9.5"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 12 L (3.17 US Gal.) Separate Fuel Tank
Weight* 26.0 Kg (57 lbs.)
Alternator Output Optional: 12V, 80W, 7A
Max. RPM Range 4,500 - 5,500
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 1 Cylinder
Output 5 ps (3.7 kw)
Displacement 102 cc (6.22 cu.in.)
Bore x Stroke 55 x 43 mm (2.17 x 1.69 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.15:1 (13:28)
Propeller Selection Range 6" - 9"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 2.5 L (0.66 US Gal.) Integral Tank
Weight* 20.0 Kg (44 lbs.)
Alternator Output Optional: 12V, 60W, 5A
Max. RPM Range 4,500 - 5,500
Start In Gear Protection Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 1 Cylinder
Output 4 ps (2.9 kw)
Displacement 102 cc (6.22 cu.in.)
Bore x Stroke 55 x 43 mm (2.17 x 1.69 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral - Reverse
Gear Ratio 2.15:1 (13:28)
Propeller Selection Range 6" - 9"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 2.5 L (0.66 US Gal.) Integral Tank
Weight* 20.0 Kg (44 lbs.)
Alternator Output Optional: 12V, 60W, 5A
Max. RPM Range 4,500 - 5,500
Start In Gear Protection Standard
Through-The-Prop Exhaust Standard
Shallow Water Drive Standard
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 1 Cylinder
Output 2.5 ps (1.8 kw)
Displacement 74.6 cc (4.55 cu.in.)
Bore x Stroke 55 x 43 mm (2.17 x 1.69 in)
Starting Manual
Control Type Tiller Handle
Gear Shift Forward - Neutral
Gear Ratio A2 type 1.85:1 (13:24), B2 type 2.15:1 (13:28)
Propeller Selection Range 4.5" - 7"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 1.4 L (0.37 US Gal.) Integral Tank
Weight* 12.5 Kg (28 lbs.)
Max. RPM Range 4,200 - 5,300
Start In Gear Protection -
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine Two Stroke 1 Cylinder
Output 2.5 ps (1.8 kw)
Displacement 74.6 cc (4.55 cu.in.)
Bore x Stroke 55 x 43 mm (2.17 x 1.69 in)
Starting Manual
Control Type Tiller Handle
Gear Ratio 1.85:1 (13:24)
Propeller Selection Range 4.5" - 7"
Transom Height 15", 20"
Fuel Unleaded Gasoline (87 Octane)
Oil Type Genuine recommended 2stroke engine oil (TCW-3)
Fuel Tank 1.4 L (0.37 US Gal.) Integral Tank
Weight* 12.5 Kg (28 lbs.)
Max. RPM Range 3,800 - 5,200
Start In Gear Protection -
Engine lubrication system Premixed Fuel
* Weight specification is based on the lightest version.
Specifications and descriptions are subject to change without notice.
Engine
Type 4-Stroke, SOHC, 60˚ V6, 24 Valve
Displacement 3,583 cc (219 cubic inches)
Bore & Stroke 89 X 96 mm
Full Throttle RPM Range 5,300 – 6,300 RPM
Rated Power 250 HP @ 5,800 RPM
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 72°
Drive
Gear Ratio 2.00:1
Gear Shift F-N-R
Alternator (Electric Start) 90-Amp (1,118 watt)
Battery Charging Power 60 Amps (756 watts)
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 660 mm/26 inches
Transom Height
X Type 635 mm/25 inches
XX Type 762 mm/30 inches
Dry Weight
X Type 280 kg/617 lbs
XX Type 285 kg/628 lbs
Engine
Type 4-Stroke, SOHC, 60˚ V6, 24 Valve
Displacement 3,583 cc (219 cubic inches)
Bore & Stroke 89 x 96 mm (3.5 x 3.8 in.)
Full Throttle RPM Range 5,000-6,000 RPM
Rated Power 200 HP @ 5,500 rpm
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 72°
Drive
Gear Ratio 2.00:1
Gear Shift F-N-R
Alternator (Electric Start) 90-Amp (1,118 watt)
Battery Charging Power 60 Amps (756 watts)
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 660 mm/26 inches
Transom Height
X Type 635 mm/25 inches
XX Type -
Dry Weight
X Type 278 kg/613 lbs
XX Type -
Engine
Type 4-Stroke DOHC 4 Cylinder/16 Valves
Displacement 2,354cc (144 cubic ins.)
Bore & Stroke 87 x 99 mm (3.43 x 3.9 ins.)
Full Throttle RPM Range 4,500-6,000RPM
Rated Power 115 HP @ 5,250 RPM
Idling Engine Speed Range 750 + 50 RPM
Optional Variable Trolling Range 650 RPM (Adjustment range: 650-900RPM)
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 68°
Drive
Gear Ratio 2.14:1 (30/14)
Gear Shift F-N-R
Alternator (Electric Start) 55 Amps Total (40 Amps Charging)
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 680 mm/22.8 inches
Transom Height
X Type 635 mm/25 inches
Dry Weight
X-Type 220 kg/485 lbs.
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Warning and protection
* Certain models
** Remote control models
Engine
Type 4-Stroke SOHC 4 Cylinder/16 Valves
Displacement 1,496 cc (91.4 cubic inches)
Bore & Stroke 73 mm x 89.4 mm (3.0 x 3.5 inches)
Full Throttle RPM Range 5,300-6,300 RPM
Rated Power 90 HP @ 5,800 RPM
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 68°
Drive
Gear Ratio 2.33:1
Gear Shift F-N-R
Alternator (Electric Start) 44 Amp
Battery Charging Power 35 Amp
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 480 mm/18.9 inches
Transom Height
L Type 508 mm/20 inches
X Type 635 mm/25 inches
Dry Weight
L-Type 163 kg/359 lbs.
X-Type 166 kg/365 lbs.
Engine
Type 4-Stroke SOHC 4 Cylinder/16 Valves
Displacement 1,496 cc (91.4 cubic inches)
Bore & Stroke 73 mm x 89.4 mm (3.0 x 3.5 inches)
Full Throttle RPM Range 5,300-6,300 RPM
Rated Power 100 HP @ 5,900 RPM
Cooling System Water Cooled
Fuel Unleaded Gas (93 Octane)
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 68°
Drive
Gear Ratio 2.33:1
Gear Shift F-N-R
Alternator (Electric Start) 44 Amp
Battery Charging Power 35 Amp
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 480 mm/18.9 inches
Transom Height
X Type 635 mm/25 inches
Dry Weight
X-Type 166 kg/365 lbs.
Engine
Type 4-Stroke SOHC 3 Cylinder/12 Valves
Displacement 998 cc (61.0 cubic inches)
Bore & Stroke 73 mm x 79.5 mm (2.9 x 3.1 inches)
Full Throttle RPM Range 5,000-6,000 RPM
Rated Power 60 HP @ 5,500 RPM
Cooling System Water Cooled
Fuel Delivery Programmed Fuel Injection
Ignition System MicroComputer Programmed
Starting System Electric
Exhaust Through Hub
Lubrication Wet Sump
Trim Range -4° to +16°
Tilt Range 60°
Steering Angle (to port and again to starboard) 30° remote, 50° tiller
Drive
Gear Ratio 2.07:1
Gear Shift F-N-R
Alternator (Electric Start) 22-Amp
Battery Charging Power 17 Amp
Power Trim & Tilt Standard
Oil Pressure Alert Standard
Temperature Alert Standard
Rev-Limiter Standard
Dimensions
Overall Width 417 mm/16.4 inches
Transom Height
L Type 521 mm/20 inches
Dry Weight
L-Type 108 kg/239 lbs.
Engine
Type 4-Stroke SOHC 2 Cylinder/4 Valves
Displacement 350 cc (21.5 cubic inches)
Bore & Stroke 59 mm x 64 mm (2.3 x 2.5 inches)
Full Throttle RPM Range 4,500-5,500 RPM
Rated Power 15 HP @ 5,000 RPM
Cooling System Water Cooled
Fuel Delivery 1 Carburetor
Starting System Electric/Recoil
Exhaust Through Hub
Lubrication Wet Sump
Trim Range 4 Stage 8°-12°-16°-20°
Tilt Range 72°
Drive
Gear Ratio 2.08:1
Gear Shift F-N-R
Equipment
Alternator with voltage regulator (Manual Start) 6-Amp (76 watt)
Propeller 4-Blade Aluminum
Diameter x Pitch, Standard 9¼ x 10 inches
Dimensions
Overall Width 350 mm/13.8 inches
Transom Height
S Type 381 mm/15 inches
L Type 508 mm/20 inches
Dry Weight
S-Type 47 kg/104 lbs.
L-Type 50 kg/110 lbs.
Engine Type 132-valve, DOHC with VCT, 60 deg. V8
Displacement [cm3] 5559
Bore x Stroke [mm] 96.0 x 96.0
Max. Prop Shaft Output [kW (ps)] @r/min 316.9 (425)/5500
Fuel Induction System Direct Fuel Injection
Engine Transom Height [mm (inch)] X: 640(25.2), U: 767(30.2), E: 894(35.2)
Dry Weight [kg] * 442-463
Starting System Electric Starter
Controls Digital Electronic Control
Tilt System Power Trim & Tilt
Lubrication System Wet Sump
Digital Network Available
Tohatsu 2-stroke EverRun benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke EverRun benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Warning and Protection
* Electric start models
Tohatsu 2-stroke EverRun benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke EverRun benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke EverRun benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Warning and protection
* Certain models
** Remote control models
Tohatsu 2-stroke Benefits
Easy operation and handling
Fundamentals for user convenience and reliability
Protection
Engine Type SOHC, In-line 2
Displacement [cm3] 498
Bore x Stroke [mm] 65.0 x 75.0
Max. Prop Shaft Output [kW (ps)] @r/min 18.4 (25) @5500
Fuel Induction System Carburetor
Engine Transom Height [mm (inch)] S: 423 (16.7), L: 550 (21.7), X: 636 (25.0) (*depending on model)
Dry Weight [kg] * 77-85
Starting System Electric Starter or Manual Starter (*depending on model)
Controls Remote Control or Tiller Handle (*depending on model)
Tilt System Manual Tilt, Power Trim & Tilt or Hydro Tilt (*depending on model)
Lubrication System Wet Sump
Digital Network Not available
